Introduction
The 3X Red Dot Magnifier enhances your red dot sight, providing up to 3x magnification for increased target accuracy. Built with a 30mm tube, this magnifier is shockproof and IPX7 waterproof, ensuring reliable performance in tough conditions.
Description
Designed to work seamlessly with red dot sights, this magnifier offers a 31ft field of view at 100 yards, a 23mm objective lens diameter, and 28mm eyepiece diameter. It provides 75mm eye relief, allowing comfortable viewing and ease of use. It passed rigorous tests, including shock resistance (1000G) and IPX7 waterproofing.
Features
- Magnification: 3x
- Objective Lens Diameter: 23mm
- Eyepiece Diameter: 28mm
- Field of View (@100yds): 31 ft
- Eye Relief: 75mm
- Light Transmission: 85%
- Exit Pupil Diameter: 8mm
- Waterproof Rating: IPX7
- Shock Resistance: 1000G
- Adjustment Range: Full Range (Up/Down/Left/Right) – All Passed
- Flip-up Mount: Smooth operation
- Interior Cleanliness: Dust-free
Specifications
| Attribute | Details |
|---|---|
| Magnification | 3x |
| Field of View | 31 ft @ 100 yds |
| Length | 115mm |
| Tube Diameter | 30mm |
| Objective Lens Diameter | 23mm |
| Eyepiece Diameter | 28mm |
| Eye Relief | 75mm |
| Light Transmission | 85% |
| Exit Pupil Diameter | 8mm |
| Waterproof Rating | IPX7 |
| Shock Resistance | 1000G |
| Adjustment Range | Full Range (Up/Down/Left/Right) |
OEM & ODM Services
-
Customization Options: Logo engraving, packaging modifications
-
MOQ: Negotiable based on customization needs
-
Lead Time: Varies depending on order volume and customization
-
Additional Support: Private labeling and custom packaging options
